H.265+
TECHNOLOGY
H.265+ Advanced Video Compression
Save Both Bandwidth And Storage. Reduce an additional 30%-50% of bitrate from H.265/ H.265+
H.265 / H.265+ DVRs
A, D
B, C, E, F
| A | B | C | |
|---|---|---|---|
| Model | LTD8504K-ST | LTD8508K-ST | LTD8516K-ST |
| Analog & HD-TVI Video In | 4 channels | 8 channels | 16 channels |
| Recording Rates | 5 MP (2560 x 1920) @ 12 fps / 3 MP (1920 x 1536) @ 15 fps / 1920 x 1080 @ 30 fps | ||
| IPC Inputs | 2 channels, up to 6 MP (3032 x 2160) | ||
| Video Output | 1 CVBS, 1 VGA / 1 HDMI, HDMI up to 1920 x 1080 | 1 CVBS, 1 VGA / 1 HDMI, HDMI output up to 4K (3840 x 2160) | |
| D | E | F | |
|---|---|---|---|
| Model | LTD8304K-ET | LTD8308K-ET | LTD8316K-ET |
| Analog & HD-TVI Video In | 4 channels | 8 channels | 16 channels |
| Recording Rates | Channel 1 up to 3 MP | Channel 1, 2 up to 3 MP | Channel 1, 2, 3, 4 up to 3 MP |
| IPC Inputs | 1 channels up to 4 MP @ 20 fps | 2 channels up to 4 MP @ 20 fps | |
| Video Output | 1 CVBS, 1 VGA / 1 HDMI, HDMI up to 1920 x 1080 | 1 CVBS, 1 VGA / 1 HDMI, HDMI output up to 4K (3840 × 2160 @ 30 Hz) | |
