| Camera |
| Image Sensor |
1/2.5" Progressive Scan CMOS |
| Min. Illumination |
Color: 0.01 lux @(F1.2, AGC ON), 0 lux with IR |
| Shutter Speed |
1/3 s to 1/10,000 s |
| Slow Shutter |
Support |
| Lens |
4mm |
| Lens Mount |
M12 |
| Iris |
IR cut filter with auto switch |
| Day & Night |
IR cut filter |
| DNR |
3D DNR |
| Wide Dynamic Range |
120dB |
| Angle Adjustment |
Pan: 0° - 355°, Tilt: 0° - 75°, Rotation: 0° - 355° |
| Compression Standard |
| Video Compression |
Main stream: H.265/H.264, Main stream: H.265/H.264, Third stream: H.265/H.264 |
| H.264 Type |
Main Profile/High Profile |
| H.264 Zip+ |
Support |
| H.265 Type |
Main Profile |
| 265+ |
Support |
| Video Bit Rate |
32 Kbps to 16 Mbps |
| Audio Compression (-S) |
G.711/G.722.1/G.726/MP2L2 |
| Audio Bit Rate (-S) |
64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-128Kbps(MP2L2) |
| Image |
| Max. Resolution |
2560×1920 |
| Frame Rate |
60Hz: 20fps (2560×1920), 30fps (2048x1536), 30fps(1920×1080), 30fps(1280×720) 50Hz: 20fps (2560×1920), 25fps (2048x1536), 25fps(1920×1080), 25fps(1280×720) |
| Sub Stream |
50Hz: 25fps (640 × 360, 352 × 288)
60Hz: 30fps (640 × 360, 352 × 240) |
| Third Stream |
50Hz: 25fps (1280 ×720)
60Hz: 30fps (1280 ×720) |
| Image Enhancement |
BLC/3D DNR |
| Image Settings |
Support rotate mode. Brightness, contrast, saturation, and sharpness are adjustable via web browser and client software |
| ROI (Region of Interest) |
Support 1 fixed region for each stream, and face dynamic tracking |
| Target Cropping |
Support |
| Day/Night Switch |
Auto/Scheduled/Alarm Triggered (-S) |
| Audio (-S) |
| Environment Noise Filtering |
Support |
| Audio I/O |
Support |
| Sampling Rate |
Max. 48kHz |
| Network |
| Network Storage |
Support microSD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR |
| Alarm Trigger |
Motion Detection, Tampering Alarm, Network Disconnected, IP Address Conflict, Illegal Login, HDD full, HDD error |
| Protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6 |
| Standard |
ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI |
| General Function |
One-key Reset, Anti-Flicker, Heartbeat, Mirror, Password Protection, Privacy Mask, Watermark, IP Address Filter |
| Interface |
| Communication Interface |
1 RJ45 10M/100M Ethernet port |
| Audio (-S) |
1 audio input (line in), 1 audio output interface |
| Alarm (-S) |
1 alarm input, 1 alarm output |
| On-board Storage |
Built-in microSD/SDHC/SDXC slot, up to 128 GB |
| Smart Feature-set |
| Behavior Analysis |
Line crossing detection, intrusion detection, unattended baggage detection, object removal detection |
| Line Crossing Detection |
Cross a pre-defined virtual line, up to 4 pre-defined virtual lines supported |
| Intrusion Detection |
Enter and loiter in a pre-defined virtual region, up to 4 pre-defined virtual regions supported |
| Object Removal Detection |
Objects removed from the pre-defined region, such as the exhibits on display. |
| Unattended Baggage Detection |
Objects left over in the pre-defined region such as the baggage, purse, dangerous materials |
| Recognition |
Face detection |
| General |
| Operating Conditions |
-30 °C to +60 °C (-22 °F to +140 °F), Humidity 95% or less (non-condensing) |
| Power Supply |
DC12V ± 10%, PoE (802.3af) |
| Power Consumption |
Max. 5W |
| IR Range |
Approx. 100ft(30 meters) |
| Protection Level |
IP67 |
| Impact Protection |
IK10 |
| Dimensions |
Φ 111 × 82.4 mm (Φ 4.4″ × 3.2″) |
| Weight |
1.1lbs (500 g) |
