| Specifications |
|
|
Camera
|
|
Image Sensor
|
1/2.8" Progressive Scan CMOS
|
|
Min. Illumination
|
Color: 0.005 Lux @ f1.2, AGC on, 0 Lux with white light
B&W: 0.0068 Lux @ f1.4, AGC on), 0 Lux with white light
|
|
Shutter Speed
|
1/3 to 1/100,000 sec.
|
|
Slow Shutter
|
Yes
|
|
Digital Noise Reduction
|
3D
|
|
WDR
|
120 dB
|
|
Range of Motion
|
3-Axis; Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360°
|
|
Lens
|
|
Focal length
|
6 to 22 mm
|
|
Lens Type
|
Motorized
|
|
Aperture
|
f1.6
|
|
Focus
|
Auto
|
|
Field of View
(FOV)
|
Horizontal: 42.4° to 17.4°
Vertical: 23.4° to 9.2°
Diagonal: 49.6° to 20°
|
|
Lens Mount
|
Φ14
|
|
Compression Standard
|
|
|
Video Compression
|
Main stream: H.264 / H.265
Sub stream: H.264 / H.265 / MJPEG
Third stream: H.264 / H.265
|
|
H.264 Type
|
Main Profile / High Profile
|
|
H.264+
|
Main stream
|
|
H.265 Type
|
Main Profile
|
|
H.265+
|
Main stream
|
|
Video Bit Rate
|
32 Kbps to 16 Mbps
|
|
Smart Features
|
|
|
Behavior Analysis
|
Line crossing, intrusion, unattended baggage, and object removal detections
|
|
Exception / Anomaly Detections
|
Scene change
|
|
Face Detection
|
Yes
|
|
Region of Interest
|
Supports 1 fixed region for main stream and sub-stream
|
|
|
|
Max. Resolution
|
1920 × 1080
|
|
Main Stream
|
50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720)
60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720)
|
|
Sub Stream
|
50 Hz: 25 fps (640 × 480, 640 × 360, 320 × 240)
60 Hz: 30 fps (640 × 480, 640 × 360, 320 × 240)
|
|
Third Stream
|
50 Hz: 25 fps (1920 × 1080, 1280×720, 640 × 360, 352 × 288)
60 Hz: 30 fps (1920 × 1080, 1280×720, 640 × 360, 352 × 240)
|
|
Image Enhancements
|
BLC / 3D DNR / HLC
|
|
Image Settings
|
Rotate mode, saturation, brightness, contrast, sharpness, AGC, and white balance adjustable by client software or web browser
|
|
