| Camera |
| Image Sensor |
1/3" progressive scan CMOS |
| Min. Illumination |
Color: 0.01 Lux @ (f2.0, AGC on), B&W: 0 Lux with IR |
| Shutter Speed |
1/3 to 1/100, 000 sec. |
| Slow Shutter |
Yes |
| Wide Dynamic Range |
120 dB |
| Day & Night Imaging |
IR cut filter |
| Angle Adjustment |
Pan: 0° to 355°, tilt: 0° to 75° |
| Lens |
| Focal Length & Field of View |
2.8 mm, horizontal 98.0°, vertical 53.1°, diagonal 114.7° |
| Lens Mount |
M12 |
| Focus |
Fixed |
| Aperture |
f2.0 |
| Illuminator |
| IR Wavelength |
850 nm |
| IR Range |
Up to 98 ft (30 m) |
| Video |
| Max. Resolution |
2560 × 1440 |
| Main Stream |
50 Hz: 20 fps (2560 × 1440) 25 fps (2304 × 1296, 1920 × 1080, 1280 × 720)
60 Hz: 20 fps (2560 × 1440) 30 fps (2304 × 1296, 1920 × 1080, 1280 × 720) |
| Sub-Stream |
50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360) |
| Video Compression |
Main stream: H.264 / H.265
Sub-stream: H.264 / H.265 / MJPEG |
| Video Bit Rate |
32 Kbps to 8 Mbps |
| H.264 Type |
Baseline Profile / Main Profile / High Profile |
| H.265 Type |
Main Profile |
| H.264+ |
Main stream |
| H.265+ |
Main stream |
| Region of Interest (ROI) |
1 fixed region for main stream and sub-stream |
| Network |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP™, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS |
| Simultaneous Live View |
Up to 6 channels |
| API |
Open Network Video Interface, ISAPI |
| User / Host |
Up to 32 users. 3 levels: Administrator, operator and user |
| Network Storage |
NAS (NFS, SMB / CIFS), ANR |
| Web Browsers |
Plug-in required live view: Internet Explorer 10+ Plug-in free live view: Chrome 57.0+, Firefox 52.0+ Local service: Chrome 57.0+, Firefox 52.0+ |
| Imaging |
| Image Settings |
Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser |
| Day / Night Switch |
Auto, Schedule, Day, Night |
| Image Enhancements |
BLC, 3D DNR |
| Interface |
| Ethernet Interface |
1 x RJ45 10/100 Mbps self-adaptive Ethernet port |
| On-Board Storage |
Built-in memory card slot supports MicroSD cards up to 256 GB |
| Built-in Microphone |
Yes |
| Hardware Reset |
Yes |
| Event Types |
| Basic Events |
Motion detection, video tampering alarm, exceptions / anomalies |
| General |
| Linkage Method |
Upload to FTP / memory card, notify surveillance center, send email, trigger recording, trigger capture |
| Camera Materials |
Aluminum alloy body |
| Camera Dimensions |
Ø 4.72 × 3.63" (Ø 120 × 92.2 mm) |
| Package Dimensions |
5.9 × 5.9 × 5.6" (150 × 150 × 141 mm) |
| Camera Weight |
Approx. 1.0 lb (440 g) |
| Package Weight |
Approx. 1.5 lb (680 g) |
| Storage Conditions |
-22° to 140° F (-30° to 60° C). Humidity: 95% or less (non-condensing) |
| Startup and Operating Conditions |
-22° to 140° F (-30° to 60° C). Humidity: 95% or less (non-condensing) |
| General Functions |
Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter |
| Power Consumption and Current |
12 VDC, 0.4 A, max. 5 W PoE: (802.3af, 36 V to 57 V), 0.2 A to 0.15 A, max. 6.5 W |
| Power Supply |
12 VDC ± 25% PoE: 802.3af, Class 3 |
| Power Interface |
Ø 5.5 mm coaxial power plug |
| Certifications |
| EMC |
FCC SDoC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC VoC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015) |
| Safety |
UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015) |
| Environmental |
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
| Protections |
IP67 (IEC 60529-2013), IK10 (IEC 62262:2002) |
