| Specifications |
| Camera |
| Image Sensor |
1/2.9" Progressive Scan CMOS |
| Min. Illumination |
Color: 0.028 Lux @ f 2.0, AGC on
0 Lux with IR |
| Shutter Speed |
1/3 to 1/100,000 sec. |
| Slow Shutter |
Yes |
| Auto-Iris |
No |
| Day & Night |
IR cut filter with auto switch |
| DNR |
3D DNR |
| Wide Dynamic Range |
True WDR 120 dB |
3-Axis Adjustment
|
Pan:0° ~ 360°, Tilt: 0° ~ 75°, Rotation: 0° ~ 360° |
| Lens |
| Focal Length |
2.8 mm |
| Aperture |
2.0 |
| Focus |
Manual |
| Lens |
2.8 mm @ f 1.6: horizontal FOV: 97°, vertical FOV: 63°, diagonal FOV: 120° |
| Lens Mount |
M12 |
| IR |
| IR Range |
up to 98 ft (30 m) |
| Wavelength |
850 nm |
| Compression Standard |
| Video Compression |
Main stream: H.265 / H.264
Sub stream: H.265 / H.264 / MJPEG
Third stream: H.265 / H.264
|
| H.264 / H.264+ Type |
Main Profile / High Profile / Main Stream and Sub Stream Support |
| H.265 / H.265+ Type |
Main Profile / Main stream and sub stream support |
| Video Bit Rate |
256 Kbps to 16 Mbps |
| Tri Stream |
Supported |
| Smart Features |
| Behavioral Analysis |
Line crossing detection, intrusion detection |
| Face Detection |
Yes |
| Region of Interest |
1 fixed region for main stream and sub-stream |
| Imaging |
| Max. Resolution |
3072 x 2048 |
| Main Stream |
50 Hz: 20 fps (3072 x 2048, 3072 x 1728, 2944 x 1656).
25 fps (2560 x 1440, 1920 x 1080, 1280 x 720)
60 Hz: 20 fps (3072 x 2048, 3072 x 1728, 2944 x 1656).
30 fps (2560 x 1440, 1920 x 1080, 1280 x 720) |
| Sub Stream |
50 Hz: 25 fps (640 x 480, 640 x 360, 320 x 240)
60 Hz: 30 fps (640 x 480, 640 x 360, 320 x 240) |
| Third Stream |
50 Hz: 25 fps (1280 x 720, 640 x 360, 352 x 288)
60 Hz: 30 fps (1280 x 720, 640 x 360, 352 x 240) |
| Image Enhancement |
BLC / 3D DNR |
| Image Setting |
Rotate mode, saturation, brightness, contrast, sharpness adjustable by client software or web browser |
| Target Cropping |
No |
| Day / Night Switch |
Day / Night / Auto / Schedule |
| Network |
| Network Storage |
Supports MicroSD / SDHC / SDXC cards (128 GB), local storage and NAS (NFS, SMB / CIFS), ANR |
| Alarm Triggers |
Motion Detection, Intrusion Detection, Line Crossing Detection, HDD Full, HDD Error, Network Disconnected, IP Address Conflict |
| Protocols |
TCP / IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| General |
One-key Reset, Anti-Flicker, Three Streams, Heartbeat, Mirror, Password Protection, Privacy Mask, Watermark, IP Address Filter |
| Standard |
ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI |
| Simultaneous Live View |
Up to 6 channels |
| User/Host |
Up to 32 users
3 levels: Administrator, Operator and User |
| Web Browsers |
IE 8+, Chrome 31.0 - 44, Firefox 30.0 - 51, Safari 8.0+ |
| Interface |
| Communication Interface |
1 x RJ45 10/100 Mbps self-adaptive Ethernet port |
| On-board Storage |
Built-in MicroSD / SDHC / SDXC slot, up to 128 GB |
| SVC |
H.264 and H.265 encoding |
Reset Button
|
Yes |
| General |
Operating Conditions
|
-22° to 140° F (-30° to 60° C)
Humidity 95% or less (non-condensing) |
| Power Supply |
12 V DC ± 25%, Φ 5.5 mm coaxial power plug
PoE (802.3af, class 3) |
Power Consumption and Current
|
12 V DC, 0.5 A, Max. 6 W, PoE (802.3af, 37 to 57 V), 0.2 A to 0.1 A, max. 7.5 W |
IP Rating
|
IP67 |
| Materials |
Metal |
| Dimensions |
Camera: 5.00″ × 3.8″ (Φ 127.3 × 95.9 mm)
Package:5.9" x 5.9" x 5.6" (Φ150 × 150 × 141 mm) |
| Weight |
Approx. 1.4 lb. (620 g)
|
|
