| Specifications |
|
Video / Audio Input
|
IP video input
|
64 channels
|
|
Up to 12 MP resolution
|
|
Two-way audio
|
1 ch, RCA (2.0 Vp-p, 1 k Ω)
|
|
Network
|
Incoming bandwidth
|
320 Mbps or 200 Mbps (when RAID is enabled)
|
|
Outgoing bandwidth
|
256 Mbps, or 200 Mbps (when RAID is enabled)
|
|
Remote connections
|
128
|
|
Video / Audio Output
|
Recording resolutions
|
3, 4, 5, 6, 8, 12 MP; 1080p; UXGA; 720p; VGA;
4CIF, DCIF, 2CIF, CIF, QCIF
|
|
CVBS output (optional)
|
1 ch, BNC (1.0 Vp-p, 75 Ω), resolutions: PAL: 704 × 576, NTSC: 704 × 480
|
|
VGA 1 / HDMI 1 output resolutions
|
HDMI 1: 4K (3840 × 2160) / 60 Hz, 4K (3840 × 2160) / 30 Hz, 2K (2560 × 1440) / 60 Hz, 1920 × 1080p / 60 Hz, 1600 × 1200 / 60 Hz, 1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz
|
|
VGA 1: 2K (2560 × 1440) / 60 Hz, 1920 × 1080p / 60 Hz, 1600 × 1200 / 60 Hz, 1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz
|
|
VGA 2 / HDMI 2 output resolutions
|
1920 × 1080p / 60 Hz, 1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz
|
|
Audio output
|
2 ch, RCA (2.0Vp-p, 1 KΩ)
|
|
Decoding
|
Decoding formats
|
H.264 / H.264+ / H.265 / H.265+ / MPEG4
|
|
Live view / playback resolution
|
3, 4, 5, 6, 8, 12 MP; 1080p; UXGA; 720p; VGA;
4CIF, DCIF, 2CIF, CIF, QCIF
|
|
Synchronous playback
|
16 ch
|
|
Capability
|
2 ch @ 12 MP (20 fps) / 4 ch @ 8 MP (25 fps) / 8 ch @ 4 MP (30 fps) / 16 ch @ 1080p (30 fps)
|
|
Network Management
|
Network protocols
|
TCP/IP, DHCP, LTS-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS
|
|
Hard Drives
|
SATA
|
8 x SATA interfaces for up to 8 x HDDs
|
|
eSATA
|
1 x eSATA interface
|
|
Capacity
|
Up to 10 TB capacity for each HDD
|
|
Disk Array
|
Array type
|
RAID 0 / 1 / 5 / 6 / 10
|
|
Number of arrays
|
4
|
|
External Interface
|
Network interface
|
2 x RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface
|
|
Serial interface
|
RS-232; RS-485; Keyboard
|
|
USB interface
|
Front panel: 2 x USB 2.0
Rear panel: 1 x USB 3.0
|
|
Alarm channels (in/out)
|
16 / 4
|
|
General
|
Power supply
|
100 to 240V AC, 50 to 60 Hz
|
|
Max. power
|
200 W
|
|
Consumption (without HDD)
|
≤ 30 W
|
|
Operating temperature
|
14° to 131° F (-10° to 55° C)
|
|
Operating humidity
|
10 to 90 %
|
|
Dimensions
(W × D × H)
|
17.5 × 18.5 × 3.5" (445 × 470 ×90 mm)
|
|
Weight (without HDD)
|
≤ 17.6 lb (8 kg)
|
|
