Platinum Advanced Level HD-TVI 8 Channel DVR - Efficient Mode Previous Platinum Advanced Level HD-TVI 8 Channel DVR - Efficient Mode
main product photo

Platinum Advanced Level HD-TVI 4 Channel DVR Compact Case - Efficient Mode

Be the first to review this product
Call for Price
Out of stock
SKU
LTD8304T-ET
In Stock
Show more Show less
Wish List Compare
  • 4 Channel HD-TVI Video Recorder
  • Support Live View, Storage, Playback up to 4 HD-TVI / Analog / Analog HD Cameras+ 1 IP Camera
  • Up to 1080P  (1920x1080) HDMI Video Output
  • Efficient Mode Recording : 960 x 1080 @30fps
  • CVBS Output
  • 1 SATA up to 6TB HDD
  • H.264/H.264 Zip+
More Information
Specifications
Video/ Audio Input
Video Compression H.264+
Video Input 4ch/ BNC (1.0 Vp-p, 75Ω), PAL / NTSC Self-adaptive
IP Input 1ch (Support ONVIF, up to 2MP resolution)
Audio Compression G.711u
Audio Input 1-ch, RCA (2.0 V-p, 1kΩ)
Two-Way Audio Input 1-ch, RCA (2.0 V-p, 1kΩ)
Video/ Audio Output
HDMI/ VGA Output 1920x1080
CVBS Output 1-ch, BNC (1.0 V-P, 1kΩ)
Frame Rate Main Stream: 1/16 fps to real time frame rate/ Sub Stream: WD1/ 4CIF@12fps, CIF/QVGA/QCIF @real time frame rate
Video Bit Rate 32 Kbps - 6Mbps
Audio Output 1-ch, RCA (Linear, 1 kΩ)
Audio Bit Rate 64 Kbps
Dual-Stream Support
Stream Type Video, Video & Audio
Synchronous Playback 4ch
Network
Remote Connections 128
Network Protocols TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, iS CSI, UPnP™, HTTPS
Hard Disk
SATA 1 SATA
Capacity Up to 6TB capacity for each disk
External Interface
Network Interface 1:10M/ 100M self-adaptive Ethernet interface
Serial Interface RS-485
USB Port 2 X USB2.0
Alarm In/ Out -
General
Power Supply DC 12V
Consumption ≤15W
Working Temperature -10°C ~ + 55°C (14°F - 131°F)
Working Humidity 10% ~ 90%
Chassis Compact 1U Chassis
Dimesnsions 315 X 242 X 45mm (12.94 X 9.5 X 1.8 inch)
Weight ≤2Kg (4.4lb)
Video
SKU LTD8304T-ET
Recorder Technology TVI DVR
Recorder Case Compact Case
Recorder Series Platinum Series
Recorder Channel 4-Channel
User Manual (4.10 MB)
Quick Start Guide (1.25 MB)
Spec Sheet (1.66 MB)
