| Camera Module |
| Image Sensor |
1/2.5" progressive scan CMOS |
| Min. Illumination |
Color: 0.005 Lux @ f 1.6, AGC on
B/W: 0.001 Lux @ f 1.6, AGC on
0 Lux with IR |
| White Balance |
Auto / Manual / ATW (Auto-tracking White Balance) / Indoor / Outdoor / Fluorescent Lamp / Sodium Lamp |
| AGC |
Auto / Manual |
| Shutter Speed |
1/1 to 1/30,000 sec. |
| Day & Night |
IR Cut Filter |
| Digital Zoom |
16× |
| Privacy Mask |
24 programmable privacy masks |
| Focus Mode |
Auto / Semi-automatic / Manual |
| WDR |
120 dB WDR |
| Lens |
| Focal Length |
4.8 to 120 mm, 25× optical |
| Zoom Speed |
Approx. 3.2 sec. (optical lens, wide-tele) |
| FOV |
Horizontal field of view: 57.6° to 2.5° (wide-tele)
Vertical field of view: 34.4° to 1.4° (wide-tele)
Diagonal field of view: 64.5° to 2.9° (wide-tele) |
| Working Distance |
10 to 1,500 mm (wide-tele) |
| Aperture Range |
1.6 to 3.5 |
| IR |
| IR Distance |
Up to 164 ft (50 m) |
| Smart IR |
Supported |
| PTZ |
| Movement Range (Pan) |
360° endless |
| Pan Speed |
Configurable, from 0.1°/s to 300°/s
Preset Speed: 350°/s |
| Movement Range (Tilt) |
From -5° to 90° (Auto-flip) |
| Tilt Speed |
Configurable, from 0.1°/s to 160°/s
Preset Speed: 200°/s |
| Proportional Zoom |
Supported |
| Presets |
300 |
| Patrol Scan |
8 patrols, up to 32 presets for each patrol |
| Pattern Scan |
4 pattern scans, record time over 10 minutes for each scan |
| Power-off Memory |
Support |
| Park Action |
Preset / Pattern Scan / Patrol Scan / Auto Scan / Tilt Scan / Random Scan / Frame Scan / Panorama Scan |
| PTZ Position Display |
Supported |
| Preset Freezing |
Supported |
| Scheduled Task |
Preset / Pattern Scan / Patrol Scan / Auto Scan / Tilt Scan / Random Scan / Frame Scan / Panorama Scan / Dome Reboot / Dome Adjust |
| Compression Standard |
| Video Compression |
Main Stream: H.265+ / H.265 / H.264+ / H.264
Sub-Stream: H.265 / H.264 / MJPEG
Third Stream: H.265 / H.264 / MJPEG |
| H.264 Type |
Baseline Profile / Main Profile / High Profile |
| H.264+ |
Supported |
| H.265 Type |
Main Profile |
| H.265+ |
Support |
| Video Bitrate |
32 kbps to 16384 kbps |
| Audio Compression |
G.711alaw / G.711ulaw / G.722 / G.726 / MP2L2 / PCM |
| Audio Bitrate |
64 Kbps (G.711) / 16 Kbps (G.722.1) / 16 Kbps (G.726) / 32 Kbps to 160 Kbps (MP2L2) |
| SVC |
Supported |
| Smart Features |
| Basic Event Detection |
Motion, Video Tampering, & Exception Detections |
| Smart Event Detection |
Audio Exception, Face, Intrusion, Line Crossing, Region Entrance / Exiting, Unattended Baggage, & Object Removal Detections |
| |
|
| ROI Encoding |
Main stream, sub-stream, and third stream respectively support two fixed areas. |
| Smart Recording |
ANR (Automatic Network Replenishment), Dual-VCA |
| Imaging |
| Max. Resolution |
2560 × 1440 |
| Main Stream |
50 Hz: 25 fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720)
50 fps (1920 × 1080, 1280 × 960, 1280 × 720)
60 Hz: 30 fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720)
60 fps (1920 × 1080, 1280 × 960, 1280 × 720) |
| Sub-Stream |
50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240) |
| tdird Stream |
50 Hz: 25 fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (2560 × 1440, 2048 × 1536, 1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240) |
| Image Enhancement |
HLC / BLC / 3D DNR / Defog / EIS / Regional Exposure / Regional Focus |
| Network |
| Network Storage |
Built-in memory card slot, supports MicroSD / SDHC / SDXC, up to 256 GB; NAS (NPS, SMB / CIPS), ANR |
| Alarm Linkage |
Alarm actions, such as Memory Card Video Record, trigger Recording, Notify Surveillance Center, Upload to FTP / Memory Card / NAS, Send Email, etc. |
| Protocols |
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP / IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour |
| API |
Open-ended, supports ONVIF, ISAPI, and CGI, supports Third-Party Management Platform |
| Simultaneous Live View |
Up to 20 channels |
| User / Host |
Up to 32 users.
3 levels: Administrator, Operator and User |
| Security Measures |
User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering |
| Web Browsers |
IE 8 to 11, Chrome 31.0 to 44, Firefox 30.0 to 51 |
| Interface |
| Audio Interface |
1 ch audio input and 1 ch audio output |
| Alarm Interface |
2 ch alarm input and 2 ch alarm output |
| Network Interface |
1 x RJ45 10/100 Mbps Ethernet Interface; PoE+ (802.3 at, class4) |
| General |
| Power |
12 V DC and PoE+ (802.3 at, class4), Max.: 18 W (IR light 5 W Max.) |
| OperatingTemperature |
-22° to 149° F (-30° to 65°C) |
| Operating Humidity |
≤ 90% |
| Protection Ratings |
IP66 Standard; TVS 4,000V Lightning Protection, Surge Protection and Voltage transient Protection |
| Materials |
ADC12, PC, PC+ABS, SUS304, POM |
| Dimensions |
Φ 6.65" × 6.34" (Φ 169 × 161 mm) |
| Weight |
Approx. 5.40 lb (2.45 kg) |
