| Specifications |
| Camera |
| Image Sensor |
1/1.8" Progressive Scan CMOS |
| Min. Illumination |
Color: 0.0005 Lux @ (f 1.0, AGC ON), B&W: 0 Lux with white supplemental light |
| Shutter Speed |
1/3 to 1/100,000 sec. |
| Slow Shutter |
Yes |
| P/N |
P/N |
| Wide Dynamic Range |
130 dB |
| Angle Adjustment |
Pan: 0° to 360°, tilt: 0° to 75°, rotate: 0° to 360° |
| Lens |
| Lens Type |
Fixed focal lens, 2.8 mm optional |
| Iris Type |
Fixed |
| Lens Type & Field of View |
2.8 mm FOV: Horizontal: 112°; vertical: 61°; diagonal: 134° |
| Depth of Focus |
2.8 mm, 2.5 m to ∞ |
| Aperture |
f 1.0 |
| Lens Mount |
M16 |
| Detection, Observation, Recognition, Identification (DORI) |
| Ranges (2.8 mm) |
D: 58 m
O: 23 m
R: 11 m
I: 2 m |
| Supplemental Lighting |
| Type |
White |
| Range |
98 ft (30 m) |
| Technology |
Smart |
| Video |
| Max. Resolution |
2688 × 1520 |
| Main Stream |
50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720) |
| Sub Stream |
50 Hz: 25 fps (640 × 480, 640 × 360)
60 Hz: 30 fps (640 × 480, 640 × 360) |
| Third Stream |
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
*Third stream is supported under certain settings. |
| Video Compression |
Main stream: H.264 / H.264+ / H.265 / H.265+
Sub-stream: H.264 / H.265 / MJPEG
Third stream: H.264 / H.265
*Third stream is supported under certain settings. |
| Video Bit Rate |
32 Kbps to 8 Mbps |
| H.264 Type |
Baseline Profile / Main Profile / High Profile |
| H.265 Type |
Main Profile |
| H.264+ |
Main Stream supported |
| H.265+ |
Main stream supported |
| Bit Rate Control |
CBR / VBR |
| Scalable Video Coding (SVC) |
H.264 and H.265 encoding |
| Region of Interest (ROI) |
1 fixed region for main stream and sub-stream |
| Audio |
| Environment Noise Filtering |
Yes |
| Audio Sampling Rates (kHz) |
8 / 16 / 32 / 44.1 / 48 |
| Audio Compression |
G.711 ulaw / G.711 alaw / G.722.1 / G.726 / MP2L2 / PCM / MP3 / AAC |
| Audio Bit Rate |
64 Kbps (G.711 ulaw / G.711 alaw) / 16 Kbps (G.722.1) / 16 Kbps (G.726) / 32 to 192 Kbps (MP2L2) / 8 to 320 Kbps (MP3) / 16 to 64 Kbps (AAC) |
| Network |
| Simultaneous Live View |
Up to 6 channels |
| API |
Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP |
| User / Host |
Up to 32 users. 3 user levels: administrator, operator and user |
| Security |
Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface |
| Network Storage |
MicroSD / SDHC / SDXC cards (up to 256 GB) local storage, and NAS (NFS, SMB / CIFS), auto network replenishment (ANR) |
| Web Browsers |
Plug-in required live view: IE 10+
Plug-in free live view: Chrome 57.0+, Firefox 52.0+
Local service: Chrome 57.0+, Firefox 52.0+ |
| Imaging |
| SNR |
≥ 52 dB |
| Day / Night Switch |
Auto, Schedule |
| Image Enhancement |
BLC, HLC, 3D DNR |
| Image Parameters Switch |
Yes |
| Image Settings |
Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser |
| Interface |
| Built-in Microphone |
Yes |
| On-board Storage |
Built-in MicroSD/ SDHC / SDXC slot, up to 256 GB |
| Hardware Reset |
Yes |
| Communication Interface |
1 x RJ45 10/100 Mbps self-adaptive Ethernet port |
| Event Types |
| Basic |
Motion detection (human and vehicle targets classification), video tampering alarm, exceptions / anomalies |
| Smart |
Scene change detection |
| Deep Learning Functions |
| Face Capture |
Yes |
| Perimeter Protections |
Line crossing, intrusion, region entrance, & region exiting detections |
| General Information |
| Linkage Method |
Upload to NAS / memory card / FTP, notify surveillance center, trigger recording, trigger capture, send email |
| Web Client Languages (33) |
English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| General Functions |
Anti-flicker, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter |
| Software Reset |
Yes |
| Storage Conditions |
-22° to 140° F (-30° to 60° C). Humidity 95% or less (non-condensing) |
| Startup and Operating Conditions |
-22° to 140° F (-30° to 60 °C). Humidity 95% or less (non-condensing) |
| Power Supply |
12 VDC ± 25%, reverse polarity protection
PoE: 802.3af, Class 3 |
| Power Consumption and Current |
12V DC, 0.55 A, max. 6.6 W PoE (802.3 af, 36 V to 57 V), 0.22 A to 0.13 A, max. 7.6 W |
| Power Interface |
Ø 5.5 mm coaxial power plug |
| Materials |
Aluminum alloy body, except for trim ring |
| Screw Material |
SUS304 |
| Camera Dimensions |
Ø 5.4 × 4.9" (Ø 138.3 × 125.2 mm) |
| Package Dimensions |
7 × 7 × 5.9" (170 × 170 × 150 mm) |
| Camera Weight |
Approx. 1.7 lb (750 g) |
| Shipping Weight |
Approx. 2.3 lb (1,055 g) |
| Certifications |
| EMC |
FCC SDoC (47 CFR Part 15, Subpart B)
CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014)
RCM (AS/NZS CISPR 32: 2015)
IC VoC (ICES-003: Issue 6, 2016)
KC (KN 32: 2015, KN 35: 2015) |
| Safety |
UL (UL 60950-1)
CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014)
CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014)
BIS (IS 13252(Part 1):2010+A1:2013+A2:2015)
LOA (IEC/EN 60950-1) |
| Environmental |
CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006) |
| Protection Ratings |
IP67 (IEC 60529-2013) |
|
