| Camera |
| Image Sensor |
1/2.8" Progressive Scan CMOS |
| Effective Pixel |
1920(H) ×1080(V) |
| Min. Illumination |
Color: 0.05Lux @ (F1.6, AGC On), B/W: 0.01Lux @ (F1.6, AGC On) |
| White Balance |
Auto/Manual/ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp |
| AGC |
Auto / Manual |
| S / N Ratio |
≥ 52dB |
| Digital Noise Reduction |
3D DNR |
| Backlight compensation |
BLC |
| Wide Dynamic Range |
Digital WDR |
| Defog |
Support |
| Shutter Speed |
1 ~ 1/10,000s |
| Day & Night |
IR Cut Filter |
| Digital zoom |
16X |
| Focus Mode |
Auto / Semiautomatic / Manual |
| Privacy Mask |
2 privacy masks programmable |
| Lens |
| Focal Length |
4.7-94mm, 20x |
| Zoom Speed |
Approx 3s(Optical Wide-Tele) |
| Angle of View |
58.3 ~ 3.2 degree (Wide-Tele) |
| Min. Working Distance |
10 ~1000mm (Wide-Tele) |
| Aperture Range |
F1.6 ~ F3.5 |
| Pan and Tilt |
| Pan / Tilt Range |
Pan: 360° endless; Tilt: -2° ~ 90° (Auto Flip ) |
| Pan / Tilt Speed |
Pan manual speed: 0.1° ~ 160°/s, Pan preset speed: 160°/s
Tilt manual speed: 0.1° ~ 120°/s, Tilt preset speed: 120°/s |
| Proportional Zoom |
Rotation speed can be adjusted automatically according to zoom multiples |
| Number of Preset |
256 |
| Park action |
Pattern/Pan scan/Tilt scan/Frame scan/Panorama scan/Random scan |
| Patrol |
8 patrols, up to 32 presets per patrol |
| Power-off Memory |
Support |
| PTZ position display |
On / off |
| Preset freezing |
Support |
| Local Video and Audio |
| Alarm input / output |
1 input 0-5V DC/1 relay output,alarm response actions configurable |
| Audio input / putput |
1 mic/Line in, 2-2.4V[p-p]; output impedance: 1KΩ, ±10% / 1 output, Line level, impedance: 600Ω |
| Network |
| Ethernet |
10Base-T / 100Base-TX, RJ45 connector |
| Max. Image Resolution |
1920×1080 |
| Frame Rate |
60Hz: 30 fps (1920×1080), 30 fps (1280×720)
50Hz: 25 fps (1920×1080), 25 fps (1280×720) |
| Image Compression |
H.264/MPEG4 |
| ROI encoding |
Support 2 areas with adjustable levels |
| SVC |
Support |
| Audio Compression |
G.711u /G.711a /G.726 /MP2L2 |
| Protocols |
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE |
| Simultaneous Live View |
Up to 6 |
| Streams |
Dual Streams |
| SD Memory Card |
Built-in micro SD card slot, up to 64GB, support edge recording |
| User/Host Level |
Up to 32 users, 3 Levels: Administrator, Camera control, Live view only |
| Security Measures |
User authentication (ID and PW), Host authentication (MAC address), IP address filtering |
| Integration |
| Application programming |
Open-ended API, support Onvif, PSIA and CGI |
| Web Browser |
IE 7, IE 8, IE 9, Chrome 8 +, Firefox 3.5 +, Safari 5.02+ |
| General |
Working Temperature
/Humidity |
14°F ~122°F (-10°C ~ 50°C)
90% or less |
| Power Supply |
24VAC/PoE(802.3af), Max 12W |
| Impact Protection |
IK08 |
| Dimension |
Φ6.50”×6.61”(Φ165×168mm) |
| Weight |
Approx. 4.41Ibs (2Kg) |
Platinum IP PTZ High Speed Dome Camera 2.1MP
