| Camera |
| Image Sensor |
1/2.8" Progressive Scan CMOS |
| Min. Illumination |
F1.5, AGC On: Color: 0.02 lux, B/W : 0.002 lux, 0 lux with IR |
| White Balance |
Auto/Manual/ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp |
| AGC |
Auto / Manual |
| S / N Ratio |
≥ 52dB |
| 3D DNR |
Support |
| BLC |
Support |
| HLC |
Support |
| DWDR |
Support |
| Defog |
Support |
| Shutter Time |
1/1~ 1/10,000s |
| Day and Night |
IR Cut Filter |
| Digital Zoom |
16X |
| Privacy Mask |
8 Privacy Masks Programmable |
| Focus Mode |
Auto/Semiautomatic/Manual |
| Lens |
| Focal Length |
4.7-94mm, 20x |
| Zoom Speed |
Approx.3s (Optical Wide-Tele) |
| Angle of View |
58.3 ~ 3.2 degree (Wide-Tele) |
| Min. Working Distance |
10 ~1000mm (Wide-Tele) |
| Aperture Range |
F1.6 ~ F3.5 |
| Pan and Tilt |
| Pan Range |
Pan: 360° endless |
| Pan Speed |
Pan Manual Speed: 0.1° ~ 400°/s, Pan Preset Speed: 400° |
| Tilt Range |
-15° - 90° (Auto Flip) |
| Tilt Speed |
Tilt Manual Speed: 0.1° - 200°/s, Tilt Preset Speed: 200°/s |
| Number of Preset |
300 |
| Park Action |
Preset/Patrol/Pattern/Pan scan/Tilt scan/Random Scan/Frame scan/Panorama scan |
| Patrol |
8 Patrols, Up to 32 Presets Per Patrol |
| Scheduled Task |
Auto scan / Frame scan / Random scan / Patrol / Pattern / Preset / Panorama scan / Tilt scan / Dome reboot / Dome adjust / Aux output |
| Features |
| Detection |
Intrusion detection, Line crossing detection, Audio exception detection, Motion detection |
| ROI Encoding |
Support 4 areas with adjustable levels |
| Infrared |
| IR Distance |
492ft (150m) |
| IR Intensity |
Automatically Adjusted, depending on the Zoom Ratio |
| Input/ Output |
| Alarm Input |
2 |
| Alarm Output |
1 |
| Alarm Trigger |
Intrusion detection, Line crossing detection, Motion detection, Audio Exception Detection, Dynamic analysis, Tampe ring alarm, Network disconnect, IP address conflict, Storage exception |
| Alarm Actions |
Preset, Patrol, Pattern, Recording, Relay output, Upload center, upload FTP, email linkage |
| Audio Input |
1 Mic in/Line in interface, line input: 2-2.4V[p-p]; output impedance: 1KΩ, ±10% |
| Audio Output |
1 Audio output interface, line level, impedance: 600Ω |
| Network |
| Ethernet |
10Bas e-T / 100Base-TX, RJ45 connector |
| Max. Image Resolution |
1920×1080 |
| Frame Rate |
60Hz: 30 fps (1920×1080), 30 fps (1280×720)
50Hz: 25 fps (1920 ×1080 ), 25 fps (1280×720) |
| Sub Stream |
60Hz:30fps(704×480), 30fps(352×240), 30fps(320×240)
50Hz:25fps(704×576), 25fps(352×288), 25fps(320×240) |
| Image Compression |
H.264/MJPEG |
| Audio Compression |
G.711ulaw/G.711alaw/G.726/MP2L2/G.722 |
| Protocols |
IPv4/IPv6, HTTP, HTTPS, 802.1X, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, IC MP, D HCP, PPPoE |
| Number of Simultaneous Live View |
Up to 20 users |
| Mini SD Memory Card |
Support up to 128GB Micro SD/SDHC/SDXC card. Support Edge recording |
| User/Host Level |
Up to 32 users,3 Levels: Administrator, Operator and User |
| Security Measures |
User authentication (ID and PW),Host authentication (MAC address),IP address filtering |
| General |
| Interface for Application Programming |
Open-Ended API, support ONVIF Profile S, Profile G, PSIA and CGI |
| Power |
24 VAC & Hi-PoE , Max. 30W |
| Working Temperature/ Humidity |
-22°F ~ 149°F(-30 °C ~ 65°C),90% or less |
| Security Measures |
User authentication (ID and PW),Host authentication (MAC address),IP address filtering |
| Weatherproof Rating |
IP66 standard |
| Surge Protection Level |
TVS 4,000V lightning protection, surge protection and voltage transient protection |
| Dimensions |
Φ10.5”×14.4”(Φ266.6×365.2mm) |
| Weight |
8.8lbs(4.0kg) |
