| Specifications |
|
Camera
|
|
Image Sensor
|
1/2.7" Progressive Scan CMOS
|
|
Min. Illumination
|
Color: 0.007 Lux @ (F1.2, AGC ON), 0.012 Lux @ (F1.6, AGC ON)
|
|
Shutter Speed
|
1/3 s to 1/100,000 s
|
|
Slow Shutter
|
Yes
|
|
Focal length
|
2.8 mm
|
|
Focus
|
Fixed
|
|
Aperture
|
F1.6
|
|
FOV
|
2.8 mm, horizontal FOV: 104°, vertical FOV: 58°, diagonal FOV: 124°
|
|
Lens Mount
|
M12
|
|
Auto-Iris
|
No
|
|
Day &Night
|
IR cut filter
|
|
DNR
|
3D DNR
|
|
Wide Dynamic Range
|
120dB
|
|
3-Axis Adjustment
|
Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355°
|
|
IR
|
|
|
IR Range
|
Up to 98ft(30 m)
|
|
Wavelength
|
850 nm
|
|
Compression Standard
|
|
Video Compression
|
Main stream: H.265/H.264
Sub stream: H.265/H.264/MJPEG
|
|
H.264 Type
|
Main Profile/High Profile
|
|
H.264+
|
Main stream supports
|
|
H.265 Type
|
Main Profile
|
|
H.265+
|
Main stream supports
|
|
Video Bit Rate
|
32 Kbps to 16 Mbps
|
|
SVC
|
H.265 encoding and H.264 encoding support
|
|
|
|
Max. Resolution
|
2688 × 1520
|
|
Main Stream
|
50Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
|
|
Sub Stream
|
50Hz: 25 fps (704 × 576, 640 × 480, 352 × 288)
60Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)
|
|
Image Enhancement
|
BLC/3D DNR
|
|
Image Settings
|
Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
|
|
ROI (Region of Interest)
|
Support 1 fixed region for main stream and sub stream separately
|
|
Day/Night Switch
|
Day/Night/Auto/Schedule
|
|
Network
|
|
Network Storage
|
Support micro SD/SDHC/SDXC card (128G) local storage, NAS (NFS,SMB/CIFS), ANR
|
|
Alarm Trigger
|
Tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error
|
|
Protocols
|
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
|
|
4 MP Color247 Fixed Bullet Network Camera
