Platinum Turret HD-TVI Camera 5MP - 3.6mm

Be the first to review this product

Call for Price

In stock

SKU

LTCMHT1752N-F

In Stock

Discontinued. 5 MP, 2560 × 1944 resolution, 3.6 mm fixed focal lens, Smart IR, up to 131ft(40 m) IR distance, 4 in 1 video output (switchable TVI/AHD/CVI/CVBS), IP67

High Definition Turret 5MP HD-TVI Camera
3.6mm Fixed Lens
2560x1944@20fps
0.01 Lux, Smart IR
2 Matrix IR 2.0 LED up to 131ft
UTC Control to OSD Menu
DC 12V
IP67
4-in-1 Video Output

Show more Show less

Details

High Definition Turret 5MP HD-TVI Camera
3.6mm Fixed Lens
2560x1944@20fps
0.01 Lux, Smart IR
2 Matrix IR 2.0 LED up to 131ft
UTC Control to OSD Menu
DC 12V
IP67
4-in-1 Video Output

Specs

More Information

Specifications

Camera
Image Sensor	5 MP CMOS
Signal System	PAL/NTSC
Resolution	2560 (H) × 1944 (V)
Frame Rate	TVI: 5M@20fps, 4M@30fps, 4M@25fps, 1080p@30fps, 1080p@25fps AHD: 5M@20fps, 4M@30fps, 4M@25fps CVI: 4M@30fps, 4M@25fps CVBS: PAL/NTSC
Min. illumination	0.01 Lux@(F1.2, AGC ON), 0 Lux with IR
Shutter Time	PAL: 1/25 s to 1/50, 000 s NTSC: 1/30 s to 1/50, 000 s
Lens	3.6 mm fixed lens
Field of View	3.6 mm, horizontal FOV: 80°, vertical FOV: 63°, diagonal FOV:105°
Lens Mount	M12
Day & Night	ICR
WDR (Wide Dynamic Range)	Digital WDR
Angle Adjustment	Pan: 0 to 360°, Tilt: 0 to 75°, Rotation: 0 to 360°
Menu
Image Mode	STD/HIGH-SAT
AGC	Yes
Day/Night Mode	Auto/Color/BW (Black and White)
White Balance	Auto/Manual
AE (Auto Exposure) Mode	DWDR/BLC/HLC/Global
Noise Reduction	2D DNR
Language	English
Function	Brightness, Sharpness, Mirror, Smart IR
Interface
Video Output	Switchable TVI/AHD/CVI/CVBS
General
Operating Conditions	-40 °C to 60 °C (-40 °F to 140 °F), humidity 90% or less (non-condensing)
Power Supply	12 VDC ± 25%
Power Consumption	Max. 4.3 W
Protection Level	IP67
Material	Front Cover: Plastic Main Body: Metal
IR Range	Up to 131ft(40 m)
Communication	Up the coax, TVI output
Dimensions	Φ 109.82 mm × 91.03 mm (Φ 4.32" × 3.6")
Weight	Approx. 303 g (0.67 lb.)
