| Specifications |
|
Camera
|
|
Image Sensor
|
1/1.8" Progressive Scan CMOS
|
|
Min. Illumination
|
0.0014 @ f 1.0 (1/30 sec., AGC on)
0.002 @ f 1.2 (1/30 sec., AGC on
0 Lux with LED on
|
|
Shutter Speed
|
1/3 to 1/100,000 sec.
|
|
Slow Shutter
|
Yes
|
|
Focal length
|
2.8 mm
|
|
Focus
|
Fixed
|
|
Aperture
|
f 1.0
|
|
FOV
|
Horizontal: 102°, vertical: 51°, diagonal: 125°
|
|
Lens Mount
|
M16
|
|
Auto-Iris
|
No
|
|
DNR
|
3D DNR
|
|
Wide Dynamic Range
|
120 dB
|
|
3-Axis Adjustment
|
Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355°
|
|
Compression Standard
|
|
Video Compression
|
Main stream: H.264 / H.265
Sub stream: H.264 / H.265 / MJPEG
Third stream: H.264 / H.265
|
|
H.264 Type
|
Baseline Profile / Main Profile / High Profile
|
|
H.264+
|
Main stream supported
|
|
H.265 Type
|
Main Profile
|
|
H.265+
|
Main stream supported
|
|
Video Bit Rate
|
32 Kbps to 8 Mbps
|
|
|
|
Max. Resolution
|
2560 × 1440
|
|
Main Stream
|
50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz: 24 fps (2560 × 1440), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720)
|
|
Sub Stream
|
50 Hz: 25 fps (640 × 480, 640 × 360, 320 × 240)
60 Hz: 30 fps (640 × 480, 640 × 360, 320 × 240)
|
|
Third stream
|
50 Hz: 1 fps (1280 × 720, 640 × 480, 640 × 360, 352 × 288, 320 × 240)
60 Hz: 1 fps (1280 × 720, 640 × 480, 640 × 360, 352 × 288, 320 × 240)
|
|
Image Enhancement
|
BLC / 3D DNR / HLC / Defog
|
|
Image Settings
|
Rotate mode, saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser
|
|
Region of Interest (ROI)
|
No
|
|
Network
|
|
Network Storage
|
Supports MicroSD / SDHC / SDXC cards up to 128 GB of local storage, NAS (NFS, SMB / CIFS), ANR
|
|
Alarm Triggers
|
Motion detection, video tampering detection, network disconnected, IP address conflict, illegal login, HDD full, HDD error
|
|
Protocols
|
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour
|
|
General Functions
|
One-key reset, three streams, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
|
|
API
|
ONVIF (PROFILE S, PROFILE G), ISAPI
|
|
Simultaneous Live View
|
Up to 6 channels
|
|
User/Host
|
Up to 32 users
3 levels: Administrator, Operator and User
|
|
Web Browser
|
IE 8+, Chrome 31.0 - 44, Firefox 30.0 - 51, Safari 8.0+
|
|
Interface
|
|
Communication Interface
|
1 x RJ45 10/100 Mbps self-adaptive Ethernet port
|
|
On-board Storage
|
Built-in MicroSD / SDHC / SDXC
|
|
Reset Button
|
Yes
|
|
SVC
|
H.265 encoding and H.264 encoding support
|
|
Smart Feature-set
|
|
Behavior Analysis
|
Line crossing detection, intrusion detection
|
|
General
|
|
Operating Conditions
|
-22° to 140° F (-30° to 60° C), humidity 95% or less (non-condensing)
|
|
Power Supply
|
12 V DC ± 25%, 5.5 mm coaxial power plug PoE (802.3af, class 3)
|
|
Power Consumption
|
12 V DC, 0.5 A, max: 6 W
PoE: (802.3af, 36 to 57 V), 0.3 to 0.1 A, max: 7.5 W
|
|
Visible Light Range
|
Warm white LEDs (3,000K), up to 98 ft (30 m)
|
|
Protection Ratings
|
IP67
|
|
Materials
|
Camera body, front cover: plastic; back cover: metal
Bottom base: plastic
|
|
Dimensions
|
Camera: Φ 5.1 × 4.1″ (Φ 130 × 103.6 mm)
|
|
Weight
|
Camera: 1.1 lb (500 g)
|
|
